Properties: Conductor:tinned oxygen-free copper,good conductivity,bending resistance,corrosion resistance. Pair stranded,electromagnetic shielding,anti-electromagnetic interference. Shielding:aluminum foil+tinned copper Jacket:TPU;anti-heat,oil resistance. Certificate:RoHS 2.Application: Suitable for high-speed continuous reciprocating movement of robots,machine tools and other industrial automation equipments. 3.Specification list
Item No.
conductor
insulation
tape
shielding
composite shielded tape
composite shielded shielding
jacket
conductor resistance Ω/km(20ºC)
cores
pairs
AWG
structure
Diameter
Material
Diameter
Material
Diameter
AWG22-36C
36
6
22
TA12/0.18
0.72
SR-PVC
1.25
Aluminum doil
Braid
/
Braid
TPU
19.2
below 70
AWG24-36C
36
6
24
TA40/0.08
0.58
SR-PVC
1.10
Braid
/
Braid
TPU
17
below 105
AWG28-36C
36
6
28
TA19/0.08
0.40
SR-PVC
1.00
Braid
/
Braid
TPU
15
below 220
1.Properties: Conductor:tinned oxygen-free copper,good conductivity,corrosion resistance. Pair stranded,electromagnetic shielding,anti-electromagnetic interference. Shielding:Hairline tinned copper braided shielding;anti-interference,bend resistance Jacket:PVC;oil resistance;high flexible Certificate:UL20276,RoHS 2.Application: Suitable for continuous reciprocating movement of machine tools and other industrial automation equipments. 3.Specification list
Item No.
conductor
insulation
tape
shielding
jacket
conductor resistance Ω/km(20ºC)
cores
pairs
AWG
structure
Diameter
Material
Diameter
Material
Diameter
AWG24-5P
10
5
24
TA45/0.08
0.62
PVC
1.00
Paper
Braid
PVC
6.8
below 95
AWG24-8P
16
8
8
AWG24-10P
20
10
8.8
AWG24-20P
40
20
10.8
1.Properties: Conductor:Tinned copper,good conductivity,corrosion resistance,bending resistance. Pair stranded,electromagnetic shielding,anti-electromagnetic interference. Shielding:Aluminum foil+tinned copper braided shielding;Anti-interference,good stability Jacket:PVC;Oil resistance Certificate:UL20276,RoHS 2.Application: Suitable for motor,electronic equipment,automatic control machine tool,etc. 3.Specification list
Item No.
Conductor
Insulation
Tape
Shielding
Jacket
Conductor resistance Ω/km(20ºC)
Cores
Pairs
AWG
Structure
Diameter
Material
Diameter
Material
Diameter
AWG28-8P
16
8
28
TA7/0.127
0.38
PVC
0.58
aluminum foil
Braid
PVC
5.5
Below 235
AWG28-17P
34
17
7.2
AWG28-34P
68
34
9.2
AWG28-50P
100
50
10.5
1.Properties: Conductor:Tinned copper,good conductivity,corrosion resistance,bend resistance. Pair stranded,electromagnetic shielding,anti-electromagnetic interference. Shielding:tinned copper braided shielding;Anti-interference Jacket:PVC;Oil resistance Certificate:UL2464,RoHS 2.Application: Suitable for automatic control machine tool and other electric equipment. 3.Specification list
Item No.
Conductor
Insulation
Tape
Shielding
Jacket
Conductor resistance Ω/km(20ºC)
Cores
Pairs
AWG
Structure
Diameter
Material
Diameter
Material
Diameter
AWG28-5P
10
5
28
TA7/0.127
0.38
anti-heat PVC
1.04
Paper
Braid
anti-heat PVC
7.6
Below 235
AWG28-10P
20
10
9.0
AWG28-25P
50
25
12.8
AWG28-30P
60
30
13.6
AWG28-32P
64
32
14.2
1.Properties: Conductor:tinned oxygen-free copper,good conductivity,bending resistance,corrosion resistance. Insulation:ETFE;bending resistance,corrosion resistance. Pair stranded,electromagnetic shielding,anti-electromagnetic interference. Shielding:tinned copper braided shielding,anti-interference,excellent stability Jacket:high flexible PVC;anti-heat,anti-cold,oil resistance. Certificate:UL2517,RoHS 2.Application: Suitable for high-speed continuous reciprocating movement of robots,machine tools and other industrial automation equipments. 3.Specification list
